SYMBOL LS 4000
Hand Held Laser Bar Code Scanner

The New Benchmark in Hand-held Laser Scanners: Nothing Else Measures Up to the LS4000 Series. Feels Different, Looks Different - Is Different. For superior bar code scanning performance in a form factor designed for maximum user comfort at a price that's highly attractive,the LS4000 Series from Symbol Technologies establishes a whole new standard of excellence. The LS4000 Series introduces an all-new ergonomic form factor to scanning products. The handle has been ergonomically contoured and shaped to fit hands of all sizes and the unit is light weight and easy to use. The patented two-finger trigger is extra long, so the user can activate the scanner with the index and middle fingers, reducing index finger fatigue, enhancing comfort and providing superior sensory feedback. More external protection: The LS4000 Series features a rubber overmolded canopy that guards the top of the scanner while front bumpers provide added protection to the scan window in the front. With the LS4000 Series, Symbol introduces "Adaptive Logic" technology.

This enables the LS4000 to read damaged or poorly printed bar codes - saving time, increasing accuracy and speeding throughput. In addition, flash programming capability allows you to update or reconfigure the scanner system or applications in the field - no physical chip change is required. LS4000 Series scanners also offer built-in Advanced Data Formatting (ADF), a Symbol innovation that gives you the capability to modify the bar code data string before sending it on to the host computer. This enhances compatibility between bar coded data and the applications software, letting you program the scanner rather than modifying the application. The LS4000 Series also offers Symbol's exclusive Synapse "smart cables" for connection to many different hosts without the need for a separate interface controller. With the LS4000 Series, you simply change the cable and your scanner is compatible with every major retail and industrial host computer. Symbol's optional IntelliStand gives LS4000 Series scanners the flexibility of hands-free or hand-held scanning operation. The IntelliStand is ideal for food, drug and general merchandise point-of-purchase duty. The rugged construction and advanced ergonomic features of the LS4000 Series scanners make them the ideal solution for all your bar code scanning needs.


Specifications

Dimensions 6.7"H x 4.7"W x 3.6"D
Weight 5.75 ounces
Optics 675nm. laser diode, bidirectional scanning @ 36 scans/sec.
Resolution 4 mil
Depth of Field (Reading Distance) 0-45 inches
Readable Codes UPC/EAN, UPC/EAN with supplementals, Code 39 Full ASCII, Code 128, Codabar, Interleaved 2 of 5, Discrete 2 of 5, MSI/Plessey
Interface IBM 4680/4690, Wand Emulation, RS-232-C, OCR, OCIA, Fujitsu, ICL, NCR, Nixdorf, Omron, TEC, Sharp, Casio, POS and Computer Keyboard Wedges from IBM, DEC, Telex, NCR, WYSE, HP and other manufacturers
Electrical (varies by model) 4.5 - 14VDC +/- 10% @ 95ma (operating)
Shock Repeated 4 foot drops onto concrete surface
