Programmable POS Keybroad


Model Identification:

KB6600

  • Powerful programming ability.
  • KB-6600: programming under DOS, programming under Windows, multiple page, multiple level, whole range key content, time delay, position sense answer back code, etc.
  • KB-6600U: programming under Windows, multiple page, whole range key content, time delay, position sense answer back code, etc.).
  • True spill proof structure.
  • Reliable and pleasant key click.
  • Comfortable key size.
  • Optional blank key, double key for alternative key group layout.
  • Optional MSR (Magnetic Stripe Reader).
  • Support two types of interface, PS2 interface for KB-6600 and USB interface for KB-6600U
  • WEPOS is supported in KB-6600U.

Product brochure (PDF)


KB4000

  • A highly versatile device series composed of several security units of 4 x 10 matrix structure programmable keys, magnetic stripe card reader, smart card reader, finger print reader, iButton reader
  • Spill-proof structure.
  • Software program for non-English (European) language. 
  • Support USB interface.
  • OS support: DOS/Win98/NT/2000/XP Pro.
  • MSR, smart card reader, iButton receptor and iButton Key are option.
  • CE, FCC CLASS A.

Product brochure (PDF)


KB3100

  • Powerful programming ability (hot key programming, programming under DOS, off-line programming under DOS, programming under Windows, multiple page, multiple level, whole range key content, time delay, position sense answer back code, etc.)
  • True spill proof structure
  • Reliable and pleasant key click.
  • Optional MSR (Magnetic Stripe Reader), soft dust cover. 
  • COVERAGE: 112 Keys in 5 pages + 6 position control key + ISO MSR, individual track enable/disable +start/stop code + Alt-Num status.
  • CODE TYPE: ASCII or scan codes.
  • LANGUAGE: English or European, software configured. 
  • CONTENTS LENGTH: 1-255 byte(s)/key.
  • MULTILEVEL: 8 levels max.
  • MEMORY: 8KB
  • INTERCHARACTOR: programmable 0 -140 sec
  • COMMAND DELAY TIME: programmable 0 - 240 sec
  • RETURN SIGNAL RESPONSE: programmable 0 - 2 sec
  • CONTROL KEY: 6 positions with position change signal return 346 mm x 210 mm x 57 mm(13.6” x 8.3” x 2.2”)
  • CE, FCC, CLASS A

Product brochure (PDF)
